Alde AquaClear 3030034
Installation of Alde AquaClear for LED panel:
1. Switch o the fresh water pump and drain the water pipes to avoid leakage.
2. Assemble the Alde AquaClear UV-C (g. 2, A) with the Alde Water Carbon lter (g. 2, B).
Please note that Alde Aqua Clear UV-C should be located before the Alde Water Carbon lter in the
ow direction. (See g. 3)
3. Then install the product on the pipe/hose according to the arrow in the direction of water ow,
horizontally or vertically. When placed vertically, the water ow should be able to pump from the
bottom up through Alde AquaClear UV-C to avoid air pockets that impair the ability to clean.
4. Connect the power cable, 12 V-DC, white (+) and brown (-) so that the product receives power when
water is owing, i.e. when the vehicle's fresh water pump is running (gs. 14, 15).
5. The contact with green and yellow wire is connected to Alde LED status panel (g. 2, F).
When the LED panel is lit, it indicates that the lter is active at ow from the water pump.
If the LED status panel light does not illuminate during active water ow, something may be
wrong, contact your dealer.
g. 12
Flow direction
Connect signal cable to
Alde LED status panel.
(See Fig. 13)
Connection 12 V from the
vehicle's fresh water pump
12 mm JG joint for LLDPE hose.
(When switching to soft hoses, use
the included adapter, 3010678)
Fill in Year and Month for
mounted Alde Water Carbon lter
Units containing water must not be exposed to temperatures below freezing. If there is a risk of frost,
drain the unit. There is a glass pane in front of the product’s UVC source, and the glass is at risk of
breaking if water in the unit freezes.
