Alderlea T5 - Appliance Dimensions; Outside Air Opening Dimensions; If You Suspect a Chimney Fire; In Case of a Chimney Fire

Fig #1
Appliance Dimensions
Outside Air Opening Dimensions
25”
635mm
28 1/2”
724mm
10 1/8”
257mm
29 3/4”
756mm
We recommend that our woodburning hearth products be installed and serviced by
professionals who are certi ed in the U.S. by the National Fireplace Institute
®
(NFI) as
NFI woodburning Specialists or who are certi ed in Canada by
Wood Energy Technical Training (WETT).
080515-24 ALT5
©PACIFIC ENERGY FIREPLACE
PRODUCTS LTD.
6
If You Suspect a Chimney Fire
Signs of a chimney  re may be one or more of the following:
1. A roaring sound
2. Vibration of the chimney
3. Flames and sparks shooting out of the top of the chimney
In Case of a Chimney Fire
1. Immediately close the air inlets on the stove.
2. Evacuate the home, and call the local  re department.
3. After the chimney  re has been extinguished, the chimney must be cleaned and
checked for stress and cracking before starting another  re. Also check combustibles
around the chimney and roof.
2 5/16"
59mm
4 1/8"(105mm)
OUTSIDE AIR INLET
C
L
C
L
* CENTERLINE OF CHIMNEY
OUTLET
*
*
Fig #1a
