Fig #1
Appliance Dimensions
Outside Air Opening Dimensions
29 1/4”
28 3/4”
8 1/2”
29 13/16”
We recommend that our woodburning hearth products be installed and serviced by
professionals who are certi ed in the U.S. by the National Fireplace Institute
®
(NFI) as
NFI woodburning Specialists or who are certi ed in Canada by
Wood Energy Technical Training (WETT).
6
190313-24 AL6B
If You Suspect a Chimney Fire
Signs of a chimney re may be one or more of the following:
1. A roaring sound
2. Vibration of the chimney
3. Flames and sparks shooting out of the top of the chimney
In Case of a Chimney Fire
1. Immediately close the air inlets on the stove.
2. Evacuate the home, and call the local re department.
3. After the chimney re has been extinguished, the chimney must be cleaned and
checked for stress and cracking before starting another re. Also check combustibles
around the chimney and roof.
4 1/8"
OUTSIDE AIR INLET
3/8"
C
L
C
L
* CENTERLINE OF CHIMNEY
OUTLET
*
*
Fig #1a
