NTS16 Assembly
AFTER SALES SUPPORT
15
 1300 855 831
 support@scheppach.com.au
MODEL: NTS16 PRODUCT CODE: 706650 10/2021
Vacuuming:
Connect the suction hose (12) to the suction hose port (7). To do so, slide the end of
the suction hose (12) into the suction hose port (7). Make sure the plug-in tting on the
end of the suction hose (12) latches into the recess on the suction hose connection
(7). In the end position, turn the suction hose (12) in a clockwise direction.
Blowing:
Connect the suction hose (12) to the connection for blower function (10). Make sure
the plug-in tting on the end of the suction hose (12) latches into the recess on the
connection with blower function (10). In the end position, turn the suction hose (12) in a
clockwise direction.
Installing the plastic extension tubes, suction hose and oor nozzle (Fig. 10)
Assemble the plastic extension tubes (17) by pushing them together. Connect the
assembled plastic extension tubes with the bent end of the suction hose (12).
Fit the oor nozzle (15) or joint nozzle (16) to the other end of the assembled plastic
extension tubes.
