Assembly
19
Assembly
WARNING!
Risk of electric shock!
Improper installation may result in an
electric shock.
− Ensure that there are no cables or other
electrical lines behind the location
where the spotlight is attached.
To avoid triggering the product unintentionally,
the spotlight must be fitted firmly. If the product
moves, this has the same effect as moving heat
sources in the sensor area.
Mounting the spotlight
1. Choose a suitable surface for installation (see chapter
section “Choosing an installation location”).
2. Remove the rear panel
8
from the spotlight
7
by
unscrewing the fixing screw
6
.
3. Hold the rear panel (for wall installation) or wall bracket
12
(for corner installation) to the installation surface and
mark the installation locations.
4. Drill two holes into the wall using a drill
19
and insert the
wall plugs
17
.
