Operation
20
5. Screw the rear wall or the wall bracket to the fastening
points with screws
18
as based on the properties of the
installation surface (see Fig.C). Use a cross-head
screwdriver
20
for this purpose. Do not apply excessive
force in the process.
6. Attach the spotlight to the rear wall or wall bracket.
7. Use the fixing screw to fasten the spotlight and the rear
wall or wall bracket.
8. Tighten the fixing screw.
Operation
Configuring the sensor area
1. If necessary, turn the motion sensor housing
9
to reach
the SENS controller
3
.
2. Select the required sensor area:
− Turning the SENS controller clockwise increases the
sensor area range and the motion sensor will already
react from a distance of approx. 12 m.
− Turning the SENS controller anticlockwise decreases
the sensor area range. With the lowest setting, the
motion sensor only reacts starting at a distance of
approx. 1 m.
To further adjust the sensor area, turn the motion sensor
housing. The motion sensor housing can be turned by 90°
(see Fig.D). The sensor angle of approx. 110° (+/-10°) does not
change in the process.
− Select the required sensor area by turning the motion
sensor housing.
