14
AFTER SALES SUPPORT
support@scheppach.com.au
1300 855 831
MODEL: ASP12-ES PRODUCT CODE: 62361 10/2018
AUS
Assembly ASP12-ES
VII. Assembly
m Warning! Ensure the appliance is correctly and completely assembled
before use.
Unpacking (Fig.1.1)
1 Unlock the locking hooks (8) and remove the appliance head (3). Remove all
accessories from the container (7).
Mounting of the castors (Fig.2)
1 Place the container (7) upturned on the ground.
2 Push the castors (5) into the holes at the bottom of the container.
Mounting appliance head and handle (Fig.3)
1 Place the appliance head (3) onto the container (7). Secure the appliance head
(3) with the locking hook (8). When tting the appliance head (3), make sure that
the locking hook (7) locks into place correctly.
2 Place the handle (1) on the machine head (3) and secure it with the two screws
(14) by using a screwdriver (not included).
Fitting the lter (Fig.4/5)
Never use the appliance without a lter! Always ensure that the lters are
correctly mounted
1 Fitting the foamed plastic lter (12): For wet-vacuuming, slip the supplied foamed
plastic lter (12) over the lter basket. (Fig.4)
2 Fitting the additional lter (16): For dry vacuum cleaning always use the supplied
additional lter (16). Slip the additional lter (16) over the lter basket (9). (Fig.5)
Assembling the paper bag (Fig.6)
For vacuuming ne, dry dirt it is recommended that you use the paper bag (13). Slip
the paper bag (13) over the vacuuming hole inside of the container (7). The paper
bag (13) is suitable for dry-vacuuming only. The paper bag (13) makes it easier to
dispose of the sucked-in dust.
