AUS
ASP12-ES Assembly/Operation
AFTER SALES SUPPORT
15
1300 855 831
support@scheppach.com.au
MODEL: ASP12-ES PRODUCT CODE: 62361 10/2018
Fitting the suction hose (Fig. 7)
Connect the suction hose (11) to the corresponding connector on the wet and dry
vacuum cleaner, depending on the application required.
Vacuuming:
Connect the suction hose (11) to the suction hose connector (4).
Blowing:
Connect the suction hose (11) to the blow connector (10).
Mounting the suction tube, hose and nozzles (Fig. 8)
1 Push the 3 parts of the suction tube (19) together.
2 Connect the 3-part suction tube (19) with the suction hose (11).
3 Push the adapter (17) into the 3-part suction tube (19).
4 Mount the oor nozzle (15) or the crevice nozzle (18) onto the adapter (17).
VIII. Operation
m Warning! Switch o the appliance if liquid or foam is emitted with the ex-
haust air when wet vacuum cleaning.
On/O switch (Fig. 1.1)
Press the On/O switch (2) to switch on.
Press the On/O switch (2) again to switch o.
Dry vacuuming (Fig. 1.3)
Use the paper bag (13) and the additional lter (16) for dry vacuuming. Always en-
sure that the lters are correctly mounted.
Use for for surface cleaning applications the oor nozzle (15).
