connection (19) by simply inserting them in until they are secure. (See
Fig. C3)
7.4 Assembling the accessories for blowing
To assemble the 1.8m Heavy-Duty crush resistant vacuum hose (18) to
hose outlet - blower (9) :
1)
Insert the 1.8m Heavy-Duty crush resistant vacuum hose (18) into hose
outlet - blower (9) and align the locking pin on the body connection (17)
with the groove on the hose outlet - blower (9). (See Fig. D1)
2) Turn the 1.8m Heavy-Duty crush resistant vacuum hose (18) in a
clockwise direction to secure the hose (18) into position (See Fig. D2)
7.5 To remove or install the battery pack (1) ( not supplied )
Depress the battery pack release button (2) firmly first and then
slide the battery pack (1) out from the battery port (22). (See Fig. E1)
D1 D2
C3
