ALEAPOW K4 - Function Description and Components

Function Description
The numbering of the products features refers to the illustration of the machine on the graphics page.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10
11.
12
13
14
15
16
17
18
19
20
21
22
Saw blade
Lower blade guard
Base plate
Lower guard knob
Dust extraction port
Upper guard
Rip guide
Allen wrench
Angle adjustment scale
Bevel adjustment knob
Rip guide locking screw
Blade bolt &washer
Lock-off button
On/Off Switch
Depth adjustment scale
Depth adjustment knob
Spindle lock
Suction tube
Battery pack
Battery release button
Laser
Handle
