AR2000 SLIDING GATE OPERATOR
8
It can be adjusted
Higher bracket
Magnet
Rack
Lower bracket
Fig.8
6. Electrical
Make sure that the power is OFF before making any electrical connections. Remove the cover of
the control box, perform the wiring and replace the cover again. (Refer to Fig.9 control board
scheme and wiring notes)
Fig.9 Control board scheme
