5
4. Remove the wing-nuts and washers
from each cymbal stand.
Attach the cymbal pads to the poles.
Reattach the wing-nuts and washers
and tighten to secure the cymbal to
the pole.
5. Connect the multipin head of the
included cable snake to the port on
the bottom side of the Debut module.
Tighten the two screws to secure the
cable snake to the module.
6. Connect the labeled 1/4" cables at
the tail end of the cable snake to
each respective drum pad, cymbal
and foot pedal in the drum kit.
Secure the cables using the Velcro
strap.
Feel free to adjust the tension of each
mesh head by evenly tightening each
tension rod with the included drum
key
The tighter the tension, the more
rebound and responsive the drum
head will have. Welcome to your real
drum experience!
crash
hi-hat
snare
ride
tom 3
tom
1
tom
2
hi-hat
control
kick
control
