42 M1 Active Reference Manual
SPECIFICATIONS
ENCLOSURE
MATERIALS AND CONSTRUCTION
Front baffle painted in metallic charcoal-gray, one inch (1”) thick MDF with
radiused edges to minimize diffraction. Sides and rear baffle covered in
metallic charcoal-gray vinyl laminate, over five-eighths inch (0.625”) thick
MDF.
Dual ports with 45° inlet and flared front baffle outlet allow precise, phase
accurate woofer-to-port frequency transition. Ports also aid in cooling
internally mounted primary amplifier heat sink.
Flush mount, rubber woofer trim ring allows consistent power response
characteristic at wide off-axis angles. Flush-mount tweeter plate assures
smooth off-axis response.
UL-approved fiberglass acoustical damping material damps internal mid-
frequency reflections from rear of woofer cone before entering port, lessening
IM distortion.
TRANSDUCERS
L
OW FREQUENCY DRIVER:
6.5” (165mm) diameter dynamic driver with proprietary non-woven carbon
fiber (NWCF) cone and 1.5” diameter, long-wind voice coil.
Dampened linear rubber surround with moderate internal damping and
constant linear displacement Nomex spider. ±5 mm X-max excursion
capability.
Dual magnet structure uses top magnet in opposed (“bucking”) configuration
for magnetic shielding.
HIGH FREQUENCY DRIVER:
1” silk soft-dome tweeter with special wave guide baffle.
Low-viscosity ferrofluid cooling extends power handling while retaining
impulse response capability.
Dual magnet structure uses top magnet in opposed (“bucking”) configuration
for magnetic shielding.

Alesis M1 Active Mk2 Specifications

General

Type	Active Studio Monitor
Crossover Frequency	2.8 kHz
Woofer	6.5 inch
Tweeter	1 inch silk dome
Inputs	XLR
Input Impedance	20 kOhms balanced, 10 kOhms unbalanced
Protection	RF interference, output current limiting, over temperature, turn-on/off transient, subsonic filter
