Alesis M1ACTIVE 620 - Page 11

ALESIS M1ACTIVE520 (AS6) BOM
level Part number Title QTY ROHS
..2 0011 PT1304433 BEZEL AIRPROOF 2 PC
..2 0080 PT1304434 LED BEZEL 2 PC
..2 0410 PT1304435 TRIM RING PLATE 2 PC
..2 0021 PT1310683 KNOB POWER 2 PC
..2 0005 PT1320802 SOUND PORT 2 PC
..2 0400 RU1304417 FOOT RUBBER 6 PC
..2 0490 SC0306RBNI SCREW 2 PC ROHS
..2 0340 SC0306RICI SCREW 8 PC DCR1
..2 0360 SC0308PBBI SCREW 16 PC DCR1
..2 0370 SC0308RBNI SCREW 30 PC ROHS
..2 0350 SC0308RIBI SCREW 6 PC ROHS
..2 0460 SC0310RINI SCREW 8 PC ROHS
..2 0390 SC0406RIBI SCREW 12 PC ROHS
..2 0200 SC0410PSBI SCREW 4 PC
..2 0150 SC0418PSBI SCREW 32 PC
..2 0190 SC3520RBZI SCREW 12 PC
..2 0030 SWL21-22A POWER SWITCH 2 PC ROHS
..2 0023 TWPC05A00401 P.C. BOARD ASS'
Y
2PC
...3 0002 PC05A004 REAR PANEL PCB 2 PC
...3 0003 TWPC05A004A01 P.C. BOARD ASS'
Y
2PC
....4 0080
A
L0-16-1002 RESISTOR 14 PC ROHS
....4 0370
A
L0-16-1151 RESISTOR 8 PC
....4 0320
A
L0-16-1871 RESISTOR 2 PC ROHS
....4 0360
A
L0-16-2212 RESISTOR 2 PC
....4 0380
A
L0-16-2492 RESISTOR 2 PC
....4 0330
A
L0-16-3921 RESISTOR 2 PC ROHS
....4 0002
A
L0-16-4752 RESISTOR 4 PC ROHS
....4 0350
A
L0-16-5362 RESISTOR 2 PC
....4 0280
A
L0-16-8200 RESISTOR 8 PC
....4 0290
A
L0-16-9091 RESISTOR 2 PC ROHS
....4 0090
A
L1-20-0224 ELECT 0.22UF/50V 5% 4 PC ROHS
....4 0038
A
L2-11-7812 IC 2 PC DR103
....4 0039
A
L2-11-7912 IC 2 PC DR3
....4 0050
A
L2-21-2876
A
MP IC LM2876 2 PC DR15
....4 0040
A
L2-21-3887 IC LM3886TF 2 PC DR15
....4 0025
A
L2-51-4401 TRANSISTOR 6 PC ROHS
....4 0110
A
L2-52-5242 DIODE MMBZ5242B 2 PC ROHS
....4 0037
A
L2-72-0339 IC LM339 SOP-14 2 PC DR39
....4 0034
A
L4-15-0010 HEADER DIL 10P 0.1 2 PC ROHS
....4 0260
A
L4-15-0600 CONNECTOR 2 PC ROHS
....4 0028 CS104K10005X7
R
CAPACITOR 0.1UF/100V 22 PC ROHS
....4 0014 CS151J5005COG CERAMIC 4 PC ROHS
....4 0012 CS221J5005COG CAPACITOR 4 PC ROHS
....4 0190 CS470J5005COG CAPACITOR 47P SMD 2 PC ROHS
....4 0340 CSF103J1610P CAPACITOR 8 PC DR55
....4 0023 DIENLL4148SM DIODE SMD ENLL4148S
M
2 PC DR58
....4 0100 DIZD1N4744SM ZENER DIODE 4 PC ROHS
....4 0017 EC10650T E. CAPACITOR 6 PC ROHS
....4 0020 EC10716T E.CAPACITOR 100UF/16
V
4 PC ROHS
....4 0019 EC22650T CAPACITOR 8 PC ROHS
....4 0018 EC33650TL CAPACITOR 2 PC ROHS
....4 0021 EC47616T CAPACITOR 4 PC ROHS
....4 0030 EC47650TL ELECTRIC CAPACITOR 2 PC
