ALESIS M1ACTIVE520 (AS6) BOM
level Part number Title QTY ROHS
....4 0044 JW5206T JUMPING WIRE 44 PC ROHS
....4 0270 MT1303224 PLATE 4 PC
....4 0310 RS00018J05 RESISTOR 0Ω(SMD) 4 PC ROHS
....4 0008 RS10018J05 RESISTOR 10Ω(SMD) 16 PC ROHS
....4 0005 RS10218J05 RESISTOR 1K SMD 12 PC ROHS
....4 0003 RS10418J05 RESISTOR 100K SMD 2 PC ROHS
....4 0009 RS15318J05 RESISTOR 15K SMD 4 PC ROHS
....4 0390 SC0306RBNI SCREW 4 PC ROHS
....4 0041 TE612000402 TERMINAL(4P) 2 PC ROHS
....4 0042 TE613960201 CONNECTOR 2P 180 4 PC ROHS
....4 0035 TR2SA1179N6 TRANSIST0R 2 PC ROHS
....4 0120 TR2SC2713 TRANSISTOR 2 PC DR152
....4 0036 TR2SC2812N6 TRANSISTOR 2 PC ROHS
....4 0400 WS663309IC WASHER (3M/M SPRING 4 PC DCR1
...3 0004 TWPC05A004B01 I/O PCB ASS'
Y
2PC
....4 0150
A
L0-16-1402 RESISTOR 143K(SMD)1
%
2PC
....4 0018
A
L0-16-1821 RESISTOR 4 PC ROHS
....4 0014
A
L0-16-1822 RESISTOR 6 PC ROHS
....4 0016
A
L0-16-4021 RESISTOR 2 PC ROHS
....4 0019
A
L0-16-4321 RESISTOR 6 PC ROHS
....4 0020
A
L0-16-4641 RESISTOR 2 PC
....4 0100
A
L0-16-5621 RESISTOR 2 PC ROHS
....4 0140
A
L0-16-6981 RESISTOR 2 PC
....4 0017
A
L0-16-7681 RESISTOR 4 PC
....4 0110
A
L0-16-8251 RESISTOR 4 PC ROHS
....4 0015
A
L0-16-9091 RESISTOR 8 PC ROHS
....4 0033
A
L2-71-0074 IC 4 PC DR39
....4 0038 CN1025402101 CONNECTOR 2 PC ROHS
....4 0023 CS104K10005X7
R
CAPACITOR 0.1UF/100V 2 PC ROHS
....4 0021 CS220J5005COG CAPACITOR 4 PC ROHS
....4 0022 CS221J5005COG CAPACITOR 2 PC ROHS
....4 0031 EC10716T E.CAPACITOR 100UF/16
V
2 PC ROHS
....4 0032 EC22625T E.CAPACITOR 22UF/25V 10 PC ROHS
....4 0050 JK5031 XLR BASE 2 PC ROHS
....4 0040 JK6353-02-250 MIC BASE 2 PC ROHS
....4 0060 JW5206T JUMPING WIRE 20 PC ROHS
....4 0027 MC10350T MALYER CAPACITOR 6 PC ROHS
....4 0028 MC10450T MALYER CAPACITOR 4 PC ROHS
....4 0024 MC15250T MALYER CAPACITOR 12 PC ROHS
....4 0025 MC27250T CAPACITOR 2 PC ROHS
....4 0030 MC562100T CAPACITOR 2 PC ROHS
....4 0029 MC56350T MALYER CAPACITOR 2 PC ROHS
....4 0026 MC82250T MALYER CAPACITE
R
2 PC ROHS
....4 0130 RS00018J05 RESISTOR 0Ω(SMD) 4 PC ROHS
....4 0004 RS10218J05 RESISTOR 1K SMD 4 PC ROHS
....4 0002 RS10318J05 RESISTOR 10K SMD 10 PC ROHS
....4 0005 RS10418J05 RESISTOR 100K SMD 2 PC ROHS
....4 0001 RS47218J05 RESISTOR 4.7K SMD 4 PC ROHS
....4 0070 TE522000501 5PIN TERMINAL 2.0 2 PC
....4 0037 TE562541201 TERMINAL(2P 3UCDJ) 2 PC
....4 0036 VRR20302501 POT 20KA 25MM 2 PC
...3 0005 TWPC05A004C01 SW PCB ASS'
Y
2PC
....4 0050
A
L0-16-1402 RESISTOR 143K(SMD)1
%
4PC
