ALESIS M1ACTIVE520 (AS6) BOM
level Part number Title QTY ROHS
....4 0011
A
L0-16-1542 RESISTOR 2 PC ROHS
....4 0013
A
L0-16-1653 RESISTOR 2 PC
....4 0004
A
L0-16-1822 RESISTOR 2 PC ROHS
....4 0010
A
L0-16-2003 RESISTOR 2 PC
....4 0002
A
L0-16-4322 RESISTOR 2 PC
....4 0009
A
L0-16-4992 RESISTOR 2 PC
....4 0003
A
L0-16-6651 RESISTOR 2 PC ROHS
....4 0014
A
L0-16-8062 RESISTOR 2 PC
....4 0022
A
L2-71-0074 IC 2 PC DR39
....4 0080 CS104K10005X7
R
CAPACITOR 0.1UF/100V 2 PC ROHS
....4 0023 JW5206T JUMPING WIRE 2 PC ROHS
....4 0060 MC10350T MALYER CAPACITOR 2 PC ROHS
....4 0070 MC502100T CAPACITOR 2 PC
....4 0030 MC563100TMM CAPACTOR 4 PC ROHS
....4 0040 RS00018J05 RESISTOR 0Ω(SMD) 6 PC ROHS
....4 0001 RS11318J05 RESISTOR 2 PC ROHS
....4 0015 RS18418J05 RESISTOR 2 PC ROHS
....4 0026 SWSS71010-020
2
SWITCH 2 PC
....4 0025 SWSS71020-020
3
SWITCH 6 PC ROHS
....4 0024 TE962541201 TERMINAL 2.54MM 2 PC
...3 0006 TWPC05A004D01 LED PCB ASS'
Y
2PC
....4 0003 BALE40203-0A LED HOLDER 8 PC ROHS
....4 0030 CN0420004501 CABLE 4P 2 PC
....4 0001 LDRT34966SR2L
6
LED 10 PC ROHS
....4 0010 RS47118J05 RESISTOR 470Ω(SMD) 10 PC ROHS
....4 0020 SWSFPC12MC02 PUSH SWITCH 2 PC ROHS
....4 0002 TE812000411 TERMINAL 2 PC ROHS
..2 0710 TWPC05A01001 EQ PCB ASS'
Y
2PC
...3 0050
A
L0-16-1001 RESISTOR 10 PC ROHS
...3 0430
A
L0-16-1131 RESISTOR 2 PC
...3 0330
A
L0-16-1332 RESISTOR 13.3K SMD 1
%
2PC
...3 0460
A
L0-16-1501 RESISTOR 2 PC ROHS
...3 0280
A
L0-16-1622 RESISTOR 4 PC ROHS
...3 0450
A
L0-16-1872 RESISTOR 4 PC ROHS
...3 0350
A
L0-16-2002 RESISTOR 4 PC ROHS
...3 0400
A
L0-16-2211 RESISTOR 2 PC ROHS
...3 0230
A
L0-16-2671 RESISTOR SMD 2 PC
...3 0240
A
L0-16-2741 RESISTOR 2 PC ROHS
...3 0300
A
L0-16-3402 RESISTOR 34K SMD 1% 2 PC
...3 0440
A
L0-16-3830 RESISTOR 2 PC ROHS
...3 0470
A
L0-16-5230 RESISTOR SMD 2 PC
...3 0390
A
L0-16-5902 RESISTOR 4 PC
...3 0410
A
L0-16-6811 RESISTOR 2 PC ROHS
...3 0420
A
L0-16-7871 RESISTOR 7.87K (SMD)1 4 PC ROHS
...3 0310
A
L0-16-8060 RESISTOR 806Ω SMD 1
%
2PC
...3 0290
A
L0-16-9531 RESISTOR 9.53K (SMD)1 4 PC ROHS
...3 0010
A
L2-71-0074 IC 4 PC DR39
...3 0160 CS104Z2505Y5V CAPACITOR 0.1UF SMD 4 PC ROHS
...3 0380 CS222J5005COG CAP 2200PF NPO 0805 4 PC
...3 0250 CSF103J1610P CAPACITOR 8 PC DR55
...3 0150 CSF104J1610P CAPACITOR 12 PC DR55
...3 0140 JW5206T JUMPING WIRE 4 PC ROHS
...3 0370 PC05A010 EQ PCB 2 PC
第 4 頁，共 5 頁
