Alesis MultiMix 6 USB User Manual

TECHNICAL SPECIFICATIONS
INPUTS: Line (CH 1, 2): 10 KΩ input impedance
5.5 mV ~ 4.9 V RMS sensitivity for max output
Mic (CH 1, 2): 600 Ω input impedance balanced
700 mV RMS sensitivity for max output
Line (CH 3 – 6): 700 mV RMS sensitivity for max output
HPF (CH 1, 2): 200 Hz (-1 dB), 80 Hz (-3 dB), 20 Hz (-24 dB)
OUTPUTS: Line: 7 V RMS max
Headphone: 0.5 W into 47 Ω
SIGNAL-TO-NOISE RATIO: Line: > 92 dB
(max output; JIS A-weighted) Mic: > 62 dB
DISTORTION: < 0.02%
FREQUENCY RESPONSE: Line: 20 Hz – 20 kHz (± 0.5 dB)
Mic: 20 Hz – 15 kHz (± 0.5 dB)
CHANNEL EQUALIZER: Bass: ± 14 dB @ 80 Hz
Treble: ± 14 dB @ 12 kHz
CHANNEL FADER KILL: > 90 dB @ 1 kHz
CROSSTALK: > 85 dB @ 1 kHz
INTERFACE: USB1.1 or higher
POWER ADAPTER: 10 V AC, 500 mA
* Specifications are subject to change without notice.
www.alesis.com
7-51-0302-A

Alesis MultiMix 6 USB Specifications

Inputs

line input impedance	10 KΩ
line sensitivity for max output	5.5 mV ~ 4.9 V RMS
mic input impedance	600 Ω
mic sensitivity for max output	700 mV RMS
line sensitivity for max output (CH 3 – 6)	700 mV RMS

Outputs

line output	7 V RMS max
headphone output power	0.5 W into 47 Ω

Signal Characteristics

signal-to-noise ratio (line)	> 92 dB
signal-to-noise ratio (mic)	> 62 dB
distortion	< 0.02%

Frequency Response

line frequency response	20 Hz – 20 kHz (± 0.5 dB)
mic frequency response	20 Hz – 15 kHz (± 0.5 dB)
channel equalizer bass	± 14 dB @ 80 Hz

Additional Features

channel equalizer treble	± 14 dB @ 12 kHz
channel fader kill	> 90 dB @ 1 kHz
crosstalk	> 85 dB @ 1 kHz

Power

power adapter voltage	10 V AC
power adapter current	500 mA
interface	USB1.1 or higher
