1
Getting Started
15
Hooking up the MultiMix-8FX
This diagram will help you get the MultiMix-8FX hooked up and
ready to go. The equipment you use depends on personal
preference and on whether you’re performing live or recording.
For example, you’ll see below that the MAIN MIX OUT can be
routed to a recording device for recording, or to a PA system for
live performance.
Using Proper Cables
When connecting instruments and other equipment to the
MultiMix, it’s important that you use the appropriate types of
cables. Here are some simple but important guidelines:
y
For the mic inputs, use XLR cables.
y
For the line inputs and all other 1/4” connections, use 1/4”
mono TRS cables.
y
And use stereo RCA cables for the 2-track in and out.
Be sure to follow the
guidelines for which cables to
use (further down this page)
and the procedure for setting
levels (on the next page)
before you begin mixing.
To Next Page
