Alesis MultiMix8FX User Manual

6 Specifications
31
For the more technical-minded, here are some detailed
specifications for the MultiMix’s operating levels.
Input Channels
Mic In Sensitivity Range: -60dBu to –10dBu nominal, +5dBu
maximum
Line In Sensitivity Range: -40dBu to -+10dBu nominal,
+25dBu maximum
Mic/Line Gain Range: +10 to +60dB
Equalization
High-Pass Filter: 75Hz, 18dB/octave
High Shelving: 12kHz, +/- 15dB
Mid Bandpass/Band Reject: 2.5 kHz, +/- 15dB
Low Shelving: 80Hz, +/- 15dB
Aux Sends
Aux Send A & B Gain Range: -∞ to +10dB
Aux Returns
Aux Return A Gain Range: -∞ to +15dB
Effects Level/
Aux Return B Gain Range: -∞ to +15dB
Channel Levels
Channel Level Gain Range: -∞ to +10dB
Master Levels
Main Mix, Ctrl Room Gain
Range: -∞ to +10dB
1/4” Inputs
Stereo Aux Return Level: +4dBu nominal, +20dBu maximum
RCA Inputs
Tape In Level: -10dBV nominal, +5dBV maximum
1/4” Outputs
Main Mix, Ctrl Room,
Ext Aux Send Level: +4dBu nominal, +20dBu maximum
Headphone Output: 75 ohm output impedance
>105mW into 75 ohms, >40mW
into 600ohms
RCA Outputs
Tape Out Level: -10dBV nominal, +5dBV maximum
All measurements done over
a 22Hz – 22kHz range with a
1kHz sine wave at +18dBu
(-1dBFS) input. Impedances
are measured at 1kHz.
