Alesis Performance Service Manual

LEVEL
P/N DESCRIPTION QTY REF
1 NP213ALE55 Name Plate 1 1
1 PT1330213 Cabinet 1 2
1 RU1310657 Rubber Button 1 3
1 PT1310699 FIXED HOLDER 1 4
1 RU1310632 RUBBER DRUM PAD 1 5
1 RU1310633 RUBBER DRUM PAD 1 6
1 RU1310634 RUBBER DRUM PAD 1 7
1 RU1310635 RUBBER DRUM PAD 1 8
1 RU1310636 RUBBER DRUM PAD 1 9
1 RU1310637 RUBBER DRUM PAD 1 10
1 RU1310638 RUBBER DRUM PAD 1 11
1 RU1310639 RUBBER DRUM PAD 1 12
1 MT1304494 HOLDER PLAET 1 13
1 MT1304495 HOLDER PLAET 1 14
1 MT1304496 HOLDER PLAET 1 15
1 MT1304497 HOLDER PLAET 1 16
1 MT1304498 HOLDER PLATE 1 17
1 MT1304499 HOLDER PLATE 1 18
1 MT13044100 HOLDER PLATE 1 19
1 MT13044101 HOLDER PLATE 1 20
1 RU1340203 DRUM PAD FOAM 1 21
1 EVA1304456 EVA 8 22
1 OTAL7-00-0001 PIEZO 4.6KHZ 8 23
1 EVA1304455 EVA 2 24
1 EVA1504425 EVA 2 25
1 LCM-3244JD Liquid Crystal Display Module 1 26
1 SC0308RBNI SCREW M3X8 PRN TAPPING 17 29
1 MT132040503 Rear Panel Printing 1 31
2 MT1320405 REAL PANEL 1
1 AL9-11-1011 ALPHA KNOB 1 32
1 PT1304315 POWER CABLE RETAINER 1 33
1 PT1330313 BOTTOM CHASSIS 1 34
2 MT1304310 INSERT NUT M5 4
1 RU1330701 FOOT STAND 4 35
1 SC0410PBBI SCREW M4X10 PPB TAPPING 15 36
1 SC0315RBBI SCREW M3X15 PRB TAPPING 3 37
1 SC0306RIBI SCREW M3X6 PPB 3 38
1 SC0310PBBI SCREW M3X10 PPB TAPPING 1 39
1 SC0306RBNI SCREW M3X6 PRN Tapping 2 40
1 AL9-15-1112 CAP KNOB 1 41
1 AL7-51-0154-O Safety Manual 1
1 AL7-91-1002 GEL SILICA 2
1 CB310S064 Separate Wall 1
1 CGLDS5513ALE01 Inner Box 1
1 CN1220006201 CONNECTOR(5P) 1
1 CTLDS5513ALE01 Carton 1
1 FFC3010002502 FFC 30Pin Pitch

1.0mm Length 1
1 LAC22ALE246 Serial Bar Code Label 1
1 LAC53ALE112 Safety Label 1
1 LAC62ALE248 Bar Code Label 1
1 LAC67YAH261 Sticker 8mm Green 1
1 LAP67YAH255 Sticker 10mm red 5
1 OPLDS5ALE01 Instruction Book 1
LDS5 BOM
