8
PLEASE NOTE: As a short cut, while page four through eight are active, the
Tap Number under edition can be incremented by pushing the DELAY switch.
The Tap number will fold back to 1 when Tap 8 is passed.
MODULATING THE MULTI TAP DELAY
PARAMETERS
The Delay, Volume, Panning, and Feedback of each Tap, as well as the Master
Feedback can also be modulated by any MIDI modulation source. This can be
accomplished by referring to the "Modulating the Parameters" section of the
QuadraVerb Users Manual on page 66.
EDITING THE EQ, PITCH, DELAY AND REVERB
PARAMETERS
The parameters and mode of adjustment of the EQ, Pitch, and other Delay
sections are identical to the original 5 BAND EQ->PITCH->DELAY configuration
as found on page 76 of the QuadraVerb Users Manual.
SAMPLING
The QuadraVerb Plus now has the ability to make a 1.55 second sample of the
input being fed to it. The maximum record time is 1.55 seconds. In playback,
the sample start and length times can be altered for special effects or to trim the
playback of the sample to the actual start point of the sound. The sample can
also be played back in its entirety (one shot) or continuously repeated (looping).
The playback can be further altered by having a variety of sources to trigger the
sample. These sources include an incoming audio source, playback from the
front panel, or a MIDI note on, note off, and note number/pitch message, which
allows the sample to be played back from a MIDI keyboard.
SELECTING THE SAMPLING CONFIGURATION
Sampling is accessed through new Configuration 8. All Sampling parameters
reside under the
DELAY button while in the SAMPLING configuration.
To select this configuration, first press the
CONFIG button, then press the VALUE
buttons until the display reads:
