LEVEL P/N DESCRIPTION QTY REF
AS1 BOM
2 4-19-0407 4P CONNECTOR 1 32
2 4-70-0025 10P CONNECTOR 1 34
2 5-00-0007 SCREW 2 N8
2 5-00-1011 SCREW 8 N9
2 5-00-1308 SCREW 4 N2
2 5-02-6328 NUT 5 N7
2 5-04-0009 WASHER 4 N10
2 6-02-0036 SWITCH 1 25
2 9-01-0070 EXTRUSION REAR-PANEL 1 23
2 9-15-0175-B KNOB 1 20
2 9-15-0346 I/O CUP 1 17
2 9-34-0047 CUP GASKET 1 18
2 9-79-0294 SW POWER 1 27
2 BW653245SS WASHER 1 N11
2 NM1320802 EMULSION 2 42
2 9-79-0285 PCB ASS'Y 1 28
3 CS104K10005X7R CAPACITOR 0.1UF/100V 6 C9,11,18,20,29,31
3 0-03-0000 RESISTOR 0 Ω (SMD) 2 R41,42
3 0-05-0201 RESISTOR 200 Ω 1/2W 5% 2 R31,32
3 0-15-0100 RESISTOR 10 Ω (SMD) 8 R12~19
3 0-15-0302 RESISTOR 3K (SMD) 2 R49,50
3 0-16-1000 RESISTOR 100 Ω (SMD)1% 4 R33,34,39,40
3 0-16-1001 RESISTOR 1K(SMD)1% 5 R8,10,21,23,52
3 0-16-1002 RESISTOR 10K(SMD)1% 6 R7,9,24,35,36,48
3 0-16-1272 RESISTOR 12.7K(SMD)1% 1 R22
3 0-16-1302 RESISTOR 13.0K 1/10W 1% 4 R3,4,27,28
3 0-16-2213 RESISTOR 221K Ω (SMD)1% 1 R47
3 0-16-4321 RESISTOR 4.32K(SMD)1% 4 R5,6,25,26
3 0-16-4752 RESISTOR 47.5K(SMD)1% 7 R37,38,43~46,51
3 0-16-4991 RESISTOR 4.99K(SMD)1% 4 R1,2,29,30
3 0-16-8251 RESISTOR 8.25K(SMD)1% 2 R11,20
3 1-02-0104 CAP 0.1UF 10% 2 C48,49
3 1-08-0228 ELECT 2200UF/16V 1 C43
3 1-08-0474 ELECT 47UF/16V 2 C6,23
3 1-11-1003 ELECT100UF/50V 4 C8,10,19,21
3 1-12-0102 ELECT 10UF/63V 6 C34~37,41,45
3 1-12-0472 ELECT 47UF/63V 1 C42
3 1-20-0104 CREMAIC 0.1UF 5% 2 C13,16
3 1-55-0471
CAPACITOR 470PF 50% NPO 0805 50V
2 C12,17
3 1-55-0561 CAP 560PF NPO 8 C1~3,7,14,15,22,26
3 1-56-0104 CAP 0.1UF X7R 10%50V 7 C30,32,33,38,44,46,47
3 1-56-0151 CAP 150PF NPO 0805 6 C4,5,24,25,27,28
3 2-01-5817 DIODE IN5817 1 D5
3 2-11-2940 IC LM2940C 1 U7
3 2-11-7815 IC LM7815 TO-220 1 U1
