LEVEL P/N DESCRIPTION QTY REF
AS1 BOM
3 2-11-7915 IC LM7915 TO-220 1 U5
3 2-21-3887 IC LM3886TF 2 U2,3
3 2-50-4149 DIODE IN4148 SOT-23 2 D1,2
3 2-51-4401 TRANSISTOR 2N4401 3 Q1~3
3 2-51-4403 TRANSISTOR 2N4403 SOT-23 2 Q4,5
3 2-52-5242 DIODE MMBZ5242B 1 D3
3 2-71-0532 IC NJM5532M 1 U4
3 2-72-0339 IC LM339 1 U6
3 4-14-0020 20P DIL CONNECTOR 1 J1
3 4-15-0010 HEADER DIL 10P 0.1" 1 J4
3 4-15-0200 2P SIL CONNECTOR 2 J2,3
3 4-15-0204 HEADER SIL 4P 3.96MM 1 J5
3 5-03-0038 FIXED PLATE 1 (U7)
3 9-40-0285-A PCB 1
3 DIZDHZ36BT ZENER DIODE 1 D4
3 JW5206T JUMPING WIRE 26
2 9-79-0286 I/O PCB ASS'Y 1 38
3 JW5206T JUMPING WIRE 5 J01~J05
3 0-09-0042 VR 10KA 1 R11
3 0-15-0000 RESISTOR 0 Ω (SMD) 1 JS1
3 0-15-0100 RESISTOR 10 Ω (SMD) 1 R12
3 0-16-1000 RESISTOR 100 Ω (SMD)1% 1 R3
3 0-16-1002 RESISTOR 10K(SMD)1% 8 R1,2,4,5,7~10
3 0-16-4752 RESISTOR 47.5K(SMD)1% 1 R6
3 1-12-0102 ELECT 10UF/63V 5 C9,12~15
3 1-55-0561 CAP 560PF NPO 6 C1,2,16~19
3 1-56-0103 CAP 0.01UF X7R 1 C3
3 1-56-0104 CAP 0.1UF X7R 10%50V 10 C4~8,10,11,20~22
3 2-62-0008 IC 74AHC08D 1 U3
3 2-71-0074 IC TL074 1 U4
3 2-84-0202 IC HIN202 1 U2
3 4-05-0021 XLR JACK 1 21,J1
3 4-10-0018 DB-9 1 22,J2
3 4-15-0010 HEADER DIL 10P 0.1" 1 J3
3 9-40-0286 I/O PCB 1 19
1 9-96-0058 DSP ASS'Y 1 37
2 5-00-1308 SCREW 4 N2
2 9-10-0049-C DSP PLATE 1 1
2 9-10-0050-A POLYCARBONATE 1MM 1 3
2 9-30-0017-A KEYPAD RUBBER 1 2
2 9-79-0287 DSP PCB AS'Y 1 8
3 0-15-0150 RESISTOR 15 Ω (SMD) 1 R1
3 0-15-0331 RESISTOR 330 Ω (SMD) 6 R2,3,7~10
