LEVEL P/N DESCRIPTION QTY REF
AS1 BOM
3 0-15-0470 RESISTOR 47 Ω (SMD) 1 R18
3 0-16-1001 RESISTOR 1K(SMD)1% 6 R5,16,17,19~21
3 0-16-4751 RESISTOR 4.75K(SMD)1% 1 R4
3 0-16-4752 RESISTOR 47.5K(SMD)1% 3 R14,15,22
3 0-17-0270 RESISTOR 4X27 Ω 1 R6
3 0-31-2200 RESISTOR 4X220 1/16W 1% 3 R11~13
3 1-56-0101 CAPACITOR 100P SMD 2 C17,21
3 1-56-0104 CAP 0.1UF X7R 10%50V 19 C1~8,10~16,19,24,28,30
3 1-56-0201 CAPACITOR 20P/50V SMD 2 C9,29
3 1-56-0221 CAPACITOR 220P SMD 4 C22,23,25,26
3 1-56-0223 CAPACITOR( 陶瓷 SMD 1 C27
3 1-56-0392 CAP 3900PF NPO 2 C18,20
3 1-73-1103 CAP 100UF/6.3V 1 C31
3 2-51-4401 TRANSISTOR 2N4401 2 Q1,2
3 2-63-0126 IC 74AHCT1G126 1 U8
3 2-75-1101 IC AL1101 1 U3
3 2-75-1201 IC AL1201 2 U1,2
3 2-77-0096 IC AL3101 1 U6
3 2-79-6786 IC IC 1 U5
3 3-02-0016 GREEN LED 2 D2,4
3 3-02-0038 RED LED 2 D1,3
3 4-15-0005 5P TERMINAL TOR 2.54MM 1 (T2,T3,T4,T5,T6)
3 4-20-2000 20P CONNECTOR 2.54MM 90° 1 J1
3 7-60-0001 CRYSTAL 6.144MHZ(SMD) 1 M1
3 7-70-0014 DIFFUSION PAPER 1 5(LCD1)
3 9-10-0048-B BACKLIGHT BEXEL 1 7(LCD1)
3 9-10-0051-A DIFFUSER 2MM 1 6(LCD1)
3 9-40-1330 DSP PCB 1
3 9-61-0102 MICON PIC 2-79-1689 1 U4
3 9-61-0105 EEPROM V1.2 2-69-2564 1 U7
3 9-99-0032 GLASS LCD 1 4,LCD1
