X4_BOM_AIMS_2001-12-28_Uncosted.xls
3-02-0001 LED RED DIFFUSED ROUND T1(3mm) 17 (16)DS1, (1)DS3
3-03-0001 LED TRI-STATE 1 DS6
4-02-1000 JACK 1/4" STEREO VERTICAL MOUNT 2 J3, J4 (HEADPHONE JACKS)
4-15-0204 HEADER SIL 4-PIN 3.96mm MALE EXT-LOCKING 1
4-19-0006 CABLE 6-PIN 0.1" FILM 50mm LG. SPC 1 J5 (MAIN PCB TO HEADPHONE PCB)
4-19-0303 INTERCONNECT SIL 3-PIN 0.1" 215mm SPC 2 W1-W2
4-19-0404 INTERCONNECT SIL 4-PIN 0.1" 240mm SPC 1 W3
4-51-0016 WIRE JUMPER 16AWG 345mm 300V STRANDED 4 WY1-WY3, WX1 719602
4-51-0024 WIRE JUMPER 24AWG 40mm 300V SOLID 1 W4 719602
4-51-0116 WIRE JUMPER 16AWG 270mm 300V STRANDED 1 WX2 719602
4-51-0124 WIRE JUMPER 25AWG 75mm 300V SOLID 1 W5 719602
4-51-0165 WIRE JUMPER 22AWG 175mm 1 R62 GND PIN to R118 GND PIN
4-70-0016 CABLE RIBBON DIL 16-PIN 2.54mm 95mm M-F 2 J2, J9 (FX AND GROUPS TO REAR)
4-70-0112 CABLE RIBBON DIL 12-PIN 2.54mm 600mm M-F 1 J7 (AUX TO REAR)
4-70-1200 CABLE RIBBON 12-PIN 0.1" 200mm FDIL-MDIL 1 J8 (CR TO REAR)
4-70-1612 CABLE RIBBON DIL 16-PIN 145mm X4 8 FP-TO-REAR PNL
5-00-0126 SCREW 2.6 x 5mm PPB MACHINE 22 FOR STANDOFFS
5-03-0021 STANDOFF M2.6 x 14mm F-F BRASS X3/X4 20 PCB MOUNTING
5-03-1232 STANDOFF M2.6 x 8.5mm F-F METER-PCB X3 2 LED MOUNTING TO MAIN PCB
5-04-0034 STANDOFF PLASTIC 11.5mm-LNGTH 36 FOR ALL LEDS
6-02-0026 SWITCH DPDT PUSH-LATCH 30VDC 0.3A VERT-MNT 202
(16)S1, (16)S2, (16)S3, (16)S4, (16)S5, (16)S6, (16)S7, (16)S8, (16)S9, (16)S10, (16)S11, (1)S12, (4)S13, (4)S14, (4)S15,
(1)S16, (1)S17, (1)S18, (1)S19, (1)S20, (1)S21, (1)S22, (1)S23, (1)S24, (2)S25, (2)S26,
9-40-1259-C PCB MAIN X4 - REV C 1
9-79-0185-C ASSY PCB HEADPHONE 2
9-79-1315-C ASSY PCB PAN HYBRID 4
9-79-1319-C ASSY PCB AUX HYBRID X4 1
9-79-1320-C ASSY PCB CR HYBRID X4 1
alesis Confidential
4/9/2002 Page 6
To Next Page
