Alesis Studio 32 - Page 33

X4_BOM_AIMS_2001-12-28_Uncosted.xls
9-79-0183-C ASSY PCB PEAK HYBRID 4
0-15-0103 RES 10K OHM 1/10W 5% 0805 1 R15
0-15-0122 RES 1.2K OHM 1/10W 5% 0805 4 R3-4, R9-10
0-15-0151 RES 150 OHM 1/10W 5% 0805 1 R13
0-15-0274 RES 270K OHM 1/10W 5% 0805 8 R1-2, R5-8, R11-12
0-15-0822 RES 8.2K OHM 1/10W 5% 0805 1 R14
1-03-0474 CAP 0.47uF TANT-A SMD 10% 35V 4 C1-2, C5-6
1-57-0104 CAP 0.1uF Z5U 0805 2 C3-4
2-50-4148 DIODE SIGNAL LS4148 MELF 12 D1-12
2-72-1339 IC NJM339E QUAD COMP SMD SOP-14 2 U1-2
4-28-0001 PIN HYBRID 1-PIN (FROM ROLL) 24 2 SETS x 5 PINS, 2 SETS x 7 PINS
9-40-0183-A PCB PEAK HYBRID X4 - REV A 1
9-79-1255-C ASSY PCB EQ HYBRID 8
0-15-0102 RES 1K OHM 1/10W 5% 0805 2 R9-10
0-15-0103 RES 10K OHM 1/10W 5% 0805 2 R6, R16
0-15-0105 RES 1M OHM 1/10W 5% 0805 2 R14, R24
0-15-0123 RES 12K OHM 1/10W 5% 0805 2 R4, R21
0-15-0163 RES 16K OHM 1/10W 5% 0805 2 R3, R15
0-15-0203 RES 20K OHM 1/10W 5% 0805 4 R1-2, R5, R22
0-15-0363 RES 36K OHM 1/10W 5% 0805 2 R13, R23
0-15-0472 RES 4.7K OHM 1/10W 5% 0805 6 R11, R17, R19-20, R25-26
0-15-0512 RES 5.1K OHM 1/10W 5% 0805 2 R7-8
1-55-0030 CAP 30pF NPO 0805 2 C8, C12
1-56-0100 CAP 10pF NPO 0805 5% 100V 2 C4, C10
1-56-0101 CAP 100pF NPO 0805 5% 50V 4 C1-3, C9
1-57-0104 CAP 0.1uF Z5U 0805 2 C5-6
alesis Confidential
4/9/2002 Page 7
