X4_BOM_AIMS_2001-12-28_Uncosted.xls
2-71-0082 IC TL082 DUAL OPAMP SOP-8 4
2-71-4560 IC NJM4560E DUAL OP-AMP SOP-8 1 U1
4-28-0001 PIN HYBRID 1-PIN (FROM ROLL) 24 2 SETS x 12 PINS
9-40-1255-A PCB EQ HYBRID X4 - REV A 1
9-79-1260-C ASSY PCB REAR X4 1
0-01-1002 RES 10.0K OHM 1/8W 1% 64 (8)R13, (8)R15, (8)R17, (8)R18, (8)R21, (8)R22, (8)R25, (8)R28
0-01-1500 RES 150 OHM 1/8W 1% 32 (8)R23, (8)R24, (8)R26, (8)R27
0-01-2002 RES 20.0K OHM 1/8W 1% 32 (8)R3, (8)R4, (8)R7, (8)R8
0-01-4991 RES 4.99K OHM 1/8W 1% 32 (8)R11, (8)R12, (8)R16, (8)R19
0-96-6811 RES 6.81K OHM 1/2W 1% CFR-VM 32 (8)R1, (8)R2, (8)R5, (8)R6
1-07-0224 CAP 2200uF ELEC 20% 6.3V 5x10.2x20mm 16 (8)C13, (8)C14
1-09-0100 CAP 10uF ELEC 25V 2x5x11mm 32 (8)C7, (8)C8, (8)C9, (8)C10
1-09-0476 CAP 47uF ELEC 25V 2x5x11mm 4 (1)C202, (1)C203, (1)C204, (1)C205
1-12-0472 CAP 47uF ELEC 20% 63V 2.5x6.3x11mm 33 (8)C5, (8)C6, (8)C11, (8)C12, (1)C200
1-23-0104 CAP 0.1uF Z5U 10% 100V 0.1" 2.0x4.0x5.0mm 33 (8)C15, (8)C16, (8)C17, (8)C18, (1)C201
2-21-4560 IC NJM4560L DUAL OP-AMP 8-SIP 16 (8)U1, (8)U2
4-02-1000 JACK 1/4" STEREO VERTICAL MOUNT 90
(8)J3, (8)J4, (8)J6, (8)J7, (8)J8, (8)J9, (8)J10, (8)J11, (1)J101, (1)J102, (1)J103, (1)J104, (1)J105, (1)J106, (1)J107, (1)J108,
(1)J109, (1)J110, (1)J111, (1)J112, (1)J113, (1)J114, (1)J115, (1)J116, (1)J117, (1)J118, (1) J119, (1)J120, (1)J121,
(1)J122, (1)J123, (1)J124, (1)J125, (1)J126
4-05-0010 JACK XLR 3-PIN FEM PCB-MNT 180ø 16 (8)J1, (8)J2
4-14-0012 HEADER DIL 12-PIN 0.1" 2 J127, J130
4-14-0016 HEADER DIL 16-PIN 0.1" 2 J128, J129
4-15-0204 HEADER SIL 4-PIN 3.96mm MALE EXT-LOCKING 1 J100
4-20-0016 HEADER DIL 16-PIN 0.1" SMD 8 J12
9-40-1260-B PCB REAR X4 - REV B 1
9-79-0171-C ASSY PCB MIC/LINE MODULE 8 J5
0-15-0102 RES 1K OHM 1/10W 5% 0805 4 R20-21, R27, R30
0-15-0152 RES 1.5K OHM 1/10W 5% 0805 2 R9, R11
alesis Confidential
4/9/2002 Page 8
