X4_BOM_AIMS_2001-12-28_Uncosted.xls
0-15-0222 RES 2.2K OHM 1/10W 5% 0805 2 R4, R10
0-15-0629 RES 6.2 OHM 1/10W 5% 0805 2 R22, R28
0-15-0681 RES 680 OHM 1/10W 5% 0805 4 R7-8, R12-13
0-16-3011 RES 3.01K OHM 1/10W 1% 0805 4 R5-6, R14, R17
0-16-3321 RES 3.32K OHM 1/10W 1% 0805 4 R23-26
0-16-7501 RES 7.50K OHM 1/10W 1% 0805 8 R1-3, R15-16, R18-19, R29
1-55-0221 CAP 220pF NPO 0805 5% 100V 4 C1-4
2-51-4403 TRANS PNP 2N4403 40V 800mA SOT-23 8 Q1-8
2-71-4560 IC NJM4560E DUAL OP-AMP SOP-8 2 MIC/LIN U1-2
4-28-0001 PIN HYBRID 1-PIN (FROM ROLL) 14 1 SET x 14 PINS
9-40-0171-A PCB MIC/LINE MODULE X3 - REV A 1
9-79-1307-C ASSY PCB POWER SUPPLY X4 1
0-03-0104 RES 100K OHM 1/4W 5% 3 R2, R5, R11
0-04-1002 RES 10.0K OHM 1/4W 1% 5 R1, R8-9, R13-14
0-04-2670 RES 267 OHM 1/4W 1% 3 R3, R6, R12
0-04-2941 RES 2.94K OHM 1/4W 1% 2 R7, R10
0-21-6811 RES 6.81K OHM 1/2W 1% 1 R4
1-10-0474 CAP 4700uF ELEC 20% 35V 7.5x18x40mm 2 C7, C14
1-11-0100 CAP 10uF ELEC 50V 2x5x11mm 6 C3, C5, C8, C11, C13, C17
1-11-0105 CAP 1.0uF ELEC 50V 2x5x11mm 5 C6, C10, C12, C15-16
1-13-0104 CAP 1000uF ELEC 20% 100V 7.5x18x40mm 1 C1
1-23-0104 CAP 0.1uF Z5U 10% 100V 0.1" 2.0x4.0x5.0mm 4 C2, C4, C9, C18
2-00-4148 DIODE SIGNAL 1N4148 75V 200mA 2 D13, D16
2-01-4003 DIODE POWER 1N4003 200V 1A 10 D1-6, D11-12, D14-15
2-01-5401 DIODE POWER 1N5401 100V 3A 4 D7-10
2-03-0056 TRANS PNP SMALL-SIGNAL MPSA56RLRA 80V 500mA 1 Q1
2-03-4401 TRANS NPN GEN-PURPOSE-AMP 2N4401 40V 1A TO-92 2 Q3, Q5
