Alesis TransActive Drummer - Box Contents; Important Notes

1
HEADPHONES
MASTER
VOLUME
BASS
MID
TREBLE
iPod / AUX
VOLUME
ADJUSTABLE iPod SUPPORT
iPod DOCK
MIN
MAX
MIN
MAX
-15
+15
-15
+15
-15
+15
AUX
INPUT
INPUT
POWER
STEREO LINK
LEFT OFF RIGHT
INPUT VOLTAGE
STEREO LINK
OUTPUT
LEFT
RIGHT
LEFT
RIGHT
OUTPUT
LEFT
RIGHT
(MONO)
QUICKSTART GUIDE (ENGLISH)
1. Make sure all items listed on the front of this guide are included in the box.
2. READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE PRODUCT.
3. Study this setup diagram.
4. Place product in an appropriate position for operation.
5. Make sure all input devices such as microphones, CD players, MP3 players, and linked amplifiers/PAs
are turned off and volume settings are set at "zero."
6. Connect all devices as shown above.
7. Switch everything on in the following order.
i. audio input sources (i.e. microphones, instruments, CD/MP3 Players)
ii. TransActive Drummer
iii. any additional amplifiers
8. When shutting down, always reverse this operation by turning off:
i. any additional amplifiers
ii. TransActive Drummer
iii. audio input sources (i.e. microphones, instruments, CD/MP3 Players)
Go to http://www.alesis.com
for product registration.
IMPORTANT NOTES
If your sound is distorted at high volumes, please refer to the following troubleshooting scenarios:
• Input is clipping: Try lowering the input gain or the volume control on your sound source or music
instrument.
• Output is clipping: Lower the main volume level.
• There is too much bass: Try adjusting the tone or EQ control on your sound source to lower the bass
level. This will allow you to play the music louder before clipping (distortion) occurs.
Important:
• With all speakers, an initial "break-in" period is needed to perform at optimal levels. To properly "break-
in" your TransActive Drummer, play an audio source at medium volume for a few hours.
• For best audio quality, avoid using this device in a high RF-radiated environment.
BOX CONTENTS
 TransActive Drummer
 Power Cable (standard IEC)
 Quickstart Guide
 Safety Instructions & Warranty
Information Booklet
* Cabl
e
s
sold
separately
To an input on
additional
TransActive
Drummer
(Cable sold
separately)
DRUM MODULE MIXER
POWER
CD PLAYER, ETC.
iPod HEADPHONES
