3 System Description
Basic Equipment EHS-71, 7/8 kW
Pos
Qty
Part No. Name Remark
580974 80
Oil heater, 7 kW, 230 V
230 V
580974 81
Oil heater, 7 kW, 400 V
400 V
580974 82
Oil heater, 8 kW, 440 V
440 V
580974 83
Oil heater, 8 kW, 480 V
480 V
1 1 580974 84
Oil heater, 7 kW, 690 V
690 V
2 1 597256 01
Temperature sensor
High temp alarm
1761805 01
Safety valve, 6 bar
6 bar
3 1 1761805 02
Safety valve, 15 bar
15 bar
4 1 597256 01
Temperature sensor
543054 01
Pressure gauge
0-6 bar
5 1 543054 09
Pressure gauge
0-16 bar
6 1 1763903 01 Needle valve
7 4 1761834 01 Cu washer for G½ conn.
8 1 1763729 01
Nipple
9 1 1761834 07 Washer for G3/8 conn.
10 1 1763752 01
Self-sealing nipple
580940 80 Power Unit 7-24 kW
400V,440V,480V,690V
11 1 9017568 80
Power Unit 7-22 kW, 230 V
230V
12 1 9016858 80 Control cabinet kit
Basic Equipment EHS-71, 14/16 kW
Pos
Qty
Part No. Name Remark
580975 80
Oil heater, 7 kW, 230 V
230 V
580975 81
Oil heater, 7 kW, 400 V
400 V
580975 82
Oil heater, 8 kW, 440 V
440 V
580975 83
Oil heater, 8 kW, 480 V
480 V
1 1 580975 84
Oil heater, 7 kW, 690 V
690 V
2 1 597256 01
Temperature sensor
High temp alarm
1761805 01
Safety valve, 6 bar
6 bar
3 1 1761805 02
Safety valve, 15 bar
15 bar
4 1 597256 01
Temperature sensor
543054 01
Pressure gauge
0-6 bar
5 1 543054 09
Pressure gauge
0-16 bar
6 1 1763903 01 Needle valve
7 4 1761834 01 Cu washer for G½ conn.
8 1 1763729 01
Nipple
9 1 1761834 07 Washer for G3/8 conn.
10 1 1763752 01
Self-sealing nipple
580940 80 Power Unit 7-24 kW
400V,440V,480V,690V
11 1 9017568 80
Power Unit 7-22 kW, 230 V
230V
12 1 9016858 80 Control cabinet
kit
