HYGIENIC EQUIPMENT FOR FOOD & LIFE SCIENCES

Fig. 1. Dimensions - valve.

a. LKB-F.

b. LKB with welding ends.

Note! LKB sizes D

N 125 and 150 are with six screws.

c. LKB with male part/nut and liner.

Fig. 2. Dimensi

ons - actuators.

a. Without coupling. b. With coupling.

Gillain & Co NV | Boomsesteenweg 85, B-2630 Aartselaar | Tel. +32 3 870 60 80, Fax +32 3 870 60 89 | advice@gillain.com | www.gillain.com
