Alfa Laval LKB Manual

HYGIENIC EQUIPMENT FOR FOOD & LIFE SCIENCES
Dimensions (mm) - Valve
LKB, LKB-2, LKB -F:
Size 25 38 51 63.5 76.1 101.6 DN DN DN DN DN DN DN DN DN
mm mm mm mm mm mm 25 32 40 50 65 80 100 125 150
A 42.0 42.0 61.0 61.0 79.5 106.0 42.0 42.0 42.0 61.0 61.0 79.0 106.0 106.0 98.0
B 15.5 16.7 16.6 17.5 16.6 16.0 14.7 15.9 16.7 16.6 17.5 16.0 16.0 18.0 18.0
C 49.0 49.0 58.5 69.5 73.5 93.0 48.0 49.0 54.0 63.0 75.0 79.0 93.0 115.0 122.0
OD 25.6 38.6 51.6 64.1 76.6 102.2 30.0 36.0 42.0 54.0 70.0 85.0 104.0 129.0 154.0
ID 22.5 35.5 48.5 60.5 72.0 97.6 26.0 32.0 38.0 50.0 66.0 81.0 100.0 125.0 150.0
t 1.55 1.55 1.55 1.8 2.3 2.3 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
E 32.5 32.5 42.0 52.0 57.0 77.0 33.3 33.3 37.7 46.6 57.3 63.0 77.0 96.7 104.0
F 78.0 78.0 99.0 117.0 132.0 169.0 79.0 79.0 86.5 105.7 125.0 143.0 169.0 199.0 215.0
G 8.0 8.0 8.0 8.0 10.0 12.0 8.0 8.0 8.0 8.0 10.0 10.0 12.0 14.0 15.0
H
1
47.0 47.0 52.0 54.0 62.0 80.0 47.0 47.0 47.0 52.0 62.0 64.0 80.0 110.0 80.0
H
2
83.0 83.0 92.0 92.0 114.0 132.0 83.0 83.0 83.0 92.0 114.0 116.0 132.0 136.0 152.0
J 82.0 82.0 92.0 102.0 107.0 127.0 74.0 74.0 78.0 88.0 98.0 104.0 118.0 150.0 161.0
K 120.0 120.0 120.0 120.0 162.0 162.0 120.0 120.0 120.0 120.0 162.0 162.0 162.0 223.0 338.0
L IDF/ISO 45.0 45.0 47.5 48.5 52.5 61.5 - - - - - - - - -
M IDF/ISO 55.5 55.5 58.0 59.0 63.0 81.5 - - - - - - - - -
L DS 42.0 43.5 46.0 51.0 55.0 64.0 - - - - - - - - -
M DS 54.5 54.5 57.0 59.0 63.0 72.0 - - - - - - - - -
L SM S 38.5 43.5 46.0 51.0 55.0 75.0 - - - - - - - - -
M SMS 51.0 52.5 55.0 56.0 61.0 72.0 - - - - - - - - -
L BS 45.7 45.7 48.2 49.2 53.2 67.0 - - - - - - - - -
M BS 50.5 50.5 53.0 54.0 58.0 71.8 - - - - - - - - -
L DIN 45.5 45.5 48.0 52.0 61.0 70.0 40.0 40.0 37.0 37.0 43.0 48.0 51.0 55.0 115.0
M DIN 61.5 61.5 66.0 67.0 71.0 83.0 45.5 48.5 49.5 54.0 63.0 69.0 84.0 89.0 77.0
L Clamp 45.0 45.0 47.5 48.5 52.5 61.5 - - - - - - - - -
N 26.5 26.5 30.5 40.5 43.5 53.0 27.3 27.3 31.7 35.1 45.8 49.5 53.0 72.7 85.0
P 42.0 42.0 46.0 46.0 58.0 58.0 42.0 42.0 42.0 46.0 58.0 58.0 58.0 62.0 78.0
Weight LKB-F (kg) 1.6 1.3 2.1 2.9 5.0 7.9 1.6 1.6 1.7 2.6 4.7 5.8 7.9 11.7 12.3
Weight LKB/ LKB-2
(kg)
1.2 1.0 1.5 2.1 3.0 4.7 1.2 1.1 1.3 1.8 3.0 3.5 5.1 7.5 9.0
NOTE! Weights are for valves with welding ends and handles.
Dimensions (mm) - Actuator
LKLA and LKLA-T:
Valve 25-63.5 76.1 101.6 101.6 DN125 DN125 DN150 DN150
size DN25-50 DN65-80 DN100 DN100
A
1
244 242 242 363 246 363 246 363
A
2
193 191 191 316 195 316 195 316
A
3
244 244 244 337 244 337 244 337
A
4
173 173 173 290 173 290 173 290
D 85 85 85 133 85 133 85 133
d 1717173020302030
I 16.5 16.5 16.5 34 16.5 34 16.5 34
S 8 10 12 12 14 14 15 15
Function NC,NO,A/A NC,NO,A/A NC,NO,A/A NC,NO,A/A A/A NC,NO,A/A A/A NC,NO,A/A
Connections
Compressed air
R1/8" (BSP), internal thread.
