OPERATION INSTRUCTIONS
4
3
6
5
1 Keyboard For value selection & menus navigation
2 Display Display menu and values
3 DMX input DMX signal input - XLR 3 pin
4 DMX output DMX signal Output - XLR 3 pin
5 Fuse holder Protection fuse , replace with same value fuse
6 Power supply Input 90 - 240V~ power supply INPUT
DMX INPUT DMX OUTPUT
1:GND
2:SIGNAL +
3:SIGNAL -
FUSE: 4A
1 2
MENU
ENTER
