7-5
ENGLISH
Registers table
MODBUS protocol manual
High-Order Register
register
high
=value/10000
Low-Order Register
register
low
=value modulus10000
The 32-bit value can be retrieved by the following calculation:
value=register
high
x 10000 + register
low
Example
Value 12345678 is passed in unsigned 32-bit Modulus-10000 format.
Register
high
: 1234 = 04D2 Hex
Register
low
: 5678 = 162E Hex
value = 1234 x 10000 + 5678 = 12345678
PEAK VALUES
$00D0 4 $1068 2 PEAK OF L-N VOLTAGE PHASE 1 [mV] (Unsigned)
$00D4 4 $106A 2 PEAK OF L-N VOLTAGE PHASE 2 [mV] (Unsigned)
$00D8 4 $106C 2 PEAK OF L-N VOLTAGE PHASE 3 [mV] (Unsigned)
$00DC 4 $106E 2 PEAK OF L-L VOLTAGE 12 [mV] (Unsigned)
$00E0 4 $1070 2 PEAK OF L-L VOLTAGE 23 [mV] (Unsigned)
$00E4 4 $1072 2 PEAK OF L-L VOLTAGE 31 [mV] (Unsigned)
$00E8 4 $1074 2 PEAK OF PHASE 1 CURRENT [mA] (Signed)
$00EC 4 $1076 2 PEAK OF PHASE 2 CURRENT [mA] (Signed)
$00F0 4 $1078 2 PEAK OF PHASE 3 CURRENT [mA] (Signed)
$00F4 4 $107A 2 PEAK OF PHASE 1 CURRENT DMD [mA] (Signed)
$00F8 4 $107C 2 PEAK OF PHASE 2 CURRENT DMD [mA] (Signed)
$00FC 4 $107E 2 PEAK OF PHASE 3 CURRENT DMD [mA] (Signed)
$0100 4 $1080 2 PEAK OF NEUTRAL CURRENT [mA] (Unsigned)
$0104 4 $1082 2 PEAK OF SYSTEM ACTIVE POWER DMD [mW] (Signed)
$0108 4 $1084 2 PEAK OF SYSTEM APPARENT POWER DMD [mVA] (Signed)
DEMAND VALUES
$010C 4 $1086 2 PHASE 1 CURRENT DMD [mA] (Signed)
$0110 4 $1088 2 PHASE 2 CURRENT DMD [mA] (Signed)
$0114 4 $108A 2 PHASE 3 CURRENT DMD [mA] (Signed)
$0118 4 $108C 2 SYSTEM ACTIVE POWER DMD [mW] (Signed)
$011C 4 $108E 2 SYSTEM APPARENT POWER DMD [mVA] (Signed)
$0120 4 $1090 2 SYSTEM CURRENT DMD [mA] (Signed)
Reg. Word Reg. Word Description U. M. Sign
(IEEE) (IEEE)
