AVF7000 Operation Manual OP7000.1.1.7.R12ENG
4
4. Specifications
Size (mm) : 15, 20, 25, 32, 40, 65, 80, 100, 125, 150,
Protection Class : IP 65.
200, 250, 300, 350, 400, 450, 500 mm Explosion Proof Exd IIC T6
Measuring Range : Steam - 1.6 to 540,000 Kg/Hr Intrinsically safe Exia IIC T4
Gas - 3 to4 6,000 m3/Hr
Local Display : 2 or 3 Line LCD
Liquid - 0.3 to 4950 m3/Hr 6 digit Flowrate
Material : Stainless Steel 304 / 316 8 digit Totalizer
Accuracy
Output : 4~20 mA (2wire)
Liquid : +/- 0.7% Load : Rohm=(Vdc-12)*30
Gas/Steam : +/- 1.0%
Pulse Output : Standard Pulse Output
Repeatability : +/- 0.2% Load :
1000 000 .
Process Connection : Flange / Wafer
Communication : HART or RS485
Flange Type : JIS 10K / JIS 20K / JIS 40K
Data Storage :
Operation Parameter, Totalizer Figures
are stored by EEPROM.
ANSI 150# / ANSI 300# / ANSI 600#
Housing Material : Aluminum Alloy
DIN PN 10 / PN 16 / PN25 / PN 40
Cable Entry : 2x0.5mm2
Wafer Type : 40, 65, 80, 100, 125, 150, 200, 250
Power Supply : 12~32 VDC
without Temperature / Pressure Sensor
Keypad :
3 keys from internal for programming and
display control
Temperature :
-40 ~ +280℃ ( Standard Type)
Option
-4 ~ +420 ℃ (Explosion Proof Type)
Pressure Transmitter Pressure Compensation
Ambient Temperature :
-20 ~+60℃
Signal Input 0~30 mV DC
Pressure : 78 Kg/cm2 (Max.) Temperature Sensor Temperature Compensation
Signal Input
PT1000（2 Wire）
