AVF7000 Operation Manual OP7000.1.1.7.R12ENG

6. Installation

Installation position of Vortex Flowmeter is very important. It concerns measuring accuracy. Please leave more space of

straight pipe in upstream and downstream as best as you can. If not permitted, please install as 2/3 of total straight pipe

length on the upstream and 1/3 on downstream. However, accuracy this time can not be assured as factory accuracy.

For example:

20D

50D
