Ŷ chapter 1 getting to know the basics
2. USB Device Cover (Optional)
Underneath the cover, there is a USB connector. You may install
the optional Bluetooth module or USB thumb drive into this slot.
3. Hard Disk Drive Cover
The system’s hard disk drive is located under the cover. The
HDD can be upgraded to a larger capacity. (See Chapter 4 for
instructions on a HDD upgrade.)
4. System Device Cover
The system’s processor with cooler assembly, wireless LAN
module, and DDR memory module are located under the case
cover. You may install the WLAN module and the system
memory can be upgraded to a larger capacity. (See Chapter 4
for instructions on a memory upgrade.)
5. Ventilation Grill
The fan grill is where air is exchanged to dissipate the internal
heat. Do not block this airway completely.
Warning:
Do not block the fan grill outlet. Place the machine on hard surfaces only.
The bottom of the case may get very hot.
1-11
