chapter 4 upgrading your computer
4-7
Screw A x3
Metal Cover
Metal Cover
6. Remove 3 Screw As and remove the DIMM Metal Cover.
The DIMM socket is now seen as shown below.
DIMM Socket x2
7. If you need to remove an old DIMM from the socket,
press out on the latches located on both edges of the socket at
the same time. The DIMM should pop up to an angle of 30
degree (see diagram below.). Pull the DIMM module out of the
memory socket. Store away the DIMM for the future use.
