User's Guide Before You Begin
Left View
PCI Express Card Slot Ventilation Holes
Media Card Slot RJ 45 LAN Connector
Two USB Connectors IEEE1394 Connector
Kensington Lock Two HDD Doors
Right View
SPDIF-Out Connector
Volume Dial
Three Audio-Out Ports (Front/ Surround/ Center
speakers)
Ventilation Holes
Microphone Jack USB Connector
Headphone Jack
Page 1-5
