Theanglesthatarecalibratedareindicatedbythefollowingabbreviations,(seeFigure21).


















Figure21



Thecalibrationofthedetectorsisdividedinto8phases,whicharedescribedindetail,alsographically,in
thecalibrationprogram.

Inphases1and2thefrontandrearleftdetectorsaremountedandtheAlignmentandLeftLevelGauge
anglesarecalibrated(AFL,ARL,LFL,LRL).

Inphases3and4thefrontandreardetectorsaremountedandthe Right Alignment and Level Gauge
anglesarecalibrated(AFR,ARR,LFR,LRR).

In phases 5 and 6 the front left and front right detectors are mounted and the front convergence and
inclinationanglesarecalibrated(TFL,TFR,CFL,CFR).

In phases 7 and 8 the rear left and rear right detectors are mounted and the rear convergence and
inclinationanglesarecalibrated(TRL,TRR,CRL,CRR).




AFL AlignmentFrontLeft
AFR AlignmentFrontRight
ARL AlignmentRearLeft
ARR AlignmentRearRight
CFL CamberFrontLeft
CFR CamberFrontRight
CRL CamberRearLeft
CRR CamberRearRight
TFL ToeFrontLeft
TFR ToeFrontRight
TRL ToeRearLeft
TRR ToeRearRight
LFL LevelFrontLeft
LFR LevelFrontRight
LRL LevelRearLeft
LRR LevelRearRight
