OPERATION
SAFETY PRECAUTIONS
Accidents are preventable with your help.
■
Before operating this equipment, the following
safety information should be read and understood.
In addition, each individual working with the equip-
ment should be familiar with the safety precau-
tions.
Exercise extreme caution when hitching and removing
the attachment, operating with other workers present,
and servicing the unit.
WainRoy always makes operator safety a priority when
designing machinery. Exposed moving parts are
guarded whenever possible for safety. However, not all
moving parts can be shielded in order to ensure proper
operation. This operator’s manual and the safety decals
on the machine provide important safety information
and observed closely. If safety decals become difficult
to read, replace them immediately (see “Safety Decals”).
MANDATORY SAFETY SHUTDOWN PRO-
CEDURE
■
Failure to follow the procedures before clean-
ing, adjusting, lubricating, or servicing this unit
could lead to serious injury or death.
BEFORE cleaning, adjusting, lubricating. or servicing
this unit, ALWAYS follow the MANDATORY SAFETY
SHUTDOWN PROCEDURE:
1.
Move the skid steer loader propulsion control lever
to the “neutral” position.
2.
Shut off the attachment by shutting off the auxiliary
hydraulic output.
3.
Lower the loader lift arms completely and roll the
attachment forward so it is securely resting on firm
ground or the shop floor.
4.
Engage the loader park brake.
5.
Move the loader throttle to the slow idle position,
shut the engine off, and remove the ignition key.
6.
Keep the key with you at all times when working on
the unit so no one can start the engine without your
knowledge.
SETUP
■
Read the entire manual as well as the decals on
the attachment (see safety section) before attempt-
ing any maintenance, service, repair or setup of the
unit.
Although the Alitec Attachment is supplied fully assem-
bled, some simple checks should be performed before
operation begins.
SAFETY DECALS
The safety decals existing on the attachment should be
clearly readable and always followed. The location and
description of the decals is shown in the exploded dia-
gram. Copies of the decals are shown in “Safety
Decals” section.
LUBRICATION
All attachment wheels as well as the sideshift bars and
pivot points shown in the exploded diagram should be
greased. All bearings should be greased with a high
temperature bearing grease, EP-2 or equivalent.
DRUM ASSEMBLY
For proper operation, all picks or teeth must be installed
in all holders.
HOSES / FITTINGS
Hydraulic fittings are used to connect all attachment
hoses. All fittings should be tight and free of hydraulic
leaks. Hoses must be free of crimps or cuts that might
result in leakage. Check your attachment before oper-
ation to make sure all hose routing are kink-free and
allow for maximum movement of all sideshift, lift/lower,
and/or swing motion required during normal operation.
RETAINING RINGS
The sideshift cylinder as mounted for operation is
retained with three (3) one inch external retaining rings;
(6) in each depth cylinder and two (2) on the tilt cylin-
der.
IMPORTANT
■
The planer should not be operated at any time
when any of these rings are damaged or missing.
The planer attachment is hydraulic powered and
intended for use in milling asphalt or concrete surfaces.
The performance of the attachment can vary greatly
