SERVICE
■
BEFORE SERVICING THIS UNIT, THE MANDA-
TORY SAFETY SHUTDOWN PROCEDURE MUST
BE COMPLETED. SEE "SAFETY" SECTION.
DRUM REMOVAL
1.
With the attachment resting on a hard, flat surface,
loosen the two set screws which fix the inner
bearing race to the dead shaft.
2.
Remove the dead shaft by removing the three bolts
and nuts and pulling the dead shaft from the bearing
and out of the planer head.
3.
Remove the drive motor assembly by removing the
two mounting bolts.
4.
Remove the planetary mounting bolts.
5.
Return to the skid steer operator's seat and check
to see that all personnel are clear of the work area.
Insert the key in the ignition and start the skid steer.
6.
Sideshift the planer head slightly to the left (from the
operator's viewpoint) to remove the planetary pilot
from the planer head.
7.
Raise the attachment with the host vehicle and the
drum should remain on the floor.
8.
Shut the engine off and remove the ignition key.
■
If drum does not remain on floor, lower the
planer, shut the engine off, remove the ignition key
and review steps 1 through 4. Do not attempt to
dislodge the drum while the planer frame is in the
raised position. Never place hands or any part of
your body in, around, or under the drum as it may
fall causing serious injury.
■
Use extreme caution during this operation to
prevent planetary from tipping and falling.
PLANETARY REMOVAL
1.
Remove the drum from the attachment as
described on the previous page.
2.
Fully support the planetary with hoist and remove
the planetary flange mounting nuts.
3.
Slide the planetary from the drum with a hoist or
similar device rated for more than 250 lbs. capacity
(550 kg.).
SIDESHIFT CYLINDER REMOVAL
1.
Complete the Mandatory Safety Shutdown
Procedure.
2.
With the attachment on a level surface, remove all
three one inch retaining rings from cylinder
mounting pins.
3.
Pull the cylinder evenly from both mounting pins.
Remove the pin on the left-hand side and slide the
rod end off the backplate.
IMPORTANT
■
Remove any residual pressure in the cylinder
by cycling the loader auxiliary control from side to
side with the skid steer engine off.
SIDESHIFT FRAME REMOVAL
1.
Disconnect the drive motor hoses.
2.
Remove sideshift cylinder as described above.
3.
Remove three backplate clamp nuts and bolts and
main pivot retaining ring.
4.
Attach the planer to the skid steer and slowly
separate the sideshift frame from the chassis.
