SPECIFICATIONS
CP16ATD CP18ATD CP20ATD CP24ATD CP30ATD CP36ATD
Planing Width 16" 18" 20" 24" 30" 36"
Planing Depth 0 - 6" 0 - 6" 0 - 6" 0 - 6" 0 - 6" 0 - 6"
Hyd Horsepower 30 - 60 hp 30 - 60 hp 30 - 60 hp 30 - 60 hp 30 - 60 hp 30 - 60 hp
Sideshift Capability 22" 22" 22" 22" 22" 22"
Number of Carbide Picks 50 56 62 70 77 99
Tilt Capability ±15° ±15° ±14° ±13° ±11° ±9°
Hydraulic Flow Required 25 - 40 gpm 25 - 40 gpm 25 - 40 gpm 25 - 40 gpm 30 - 42 gpm 30 - 42 gpm
Hydraulic Pressure
Required
2000 - 3500 psi 2000 - 3500 psi 2000 - 3500 psi 2000 - 3500 psi 3000 - 3500 psi 3000 - 3500 psi
Operating Weight 1750 lbs 2000 lbs 2100 lbs 2300 lbs 2450 lbs 2600 lbs
Planetary Gear Oil Capacity 31 oz. 31 oz. 31 oz. 31 oz. 31 oz. 31 oz.
Planitary Lubricant 80 - 90W GL5 Gear Lube
GENERAL INFORMATION
The purpose of this manual is to assist you in operating
and maintaining your attachment. Read it carefully. It
furnishes information and instructions that will help you
achieve years of dependable performance. These
instructions have been compiled from extensive field
experience and engineering data. Some information
may be general in nature due to unknown and varying
operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were cur-
rent at the time of printing but, due to possible inline
production changes, your machine may vary slightly in
detail. We reserve the right to redesign and change the
machines as may be necessary without notification.
■
Some illustrations in this manual show the cold
planer with safety shields removed to provide a
better view. The cold planer should never be oper-
ated with any safety shielding removed.
Throughout this manual, references are made to right
and left direction. These are determined by standing
behind the equipment facing the direction of forward
travel.
