_ OTE: THE PARTS LISTED ABOVE ARE HELPFUL FOR LOCATING THE
CONTROLS MENTIONED BELOW,
CAUTION: PRIOR TO FIRST USING THE GENERATOR, THE ENGINE MUST BE
FILLED WiTH OiL OF A HiGH QUALITY SAE 10W-30 GRADE ENGINE OIL,
TO DO SO, UNSCREW AND REMOVE THE ENGINE'S OIL DiPSTiCK LOCATED
AT THE BOTTOM OF THE ENGINE CRANKCASE. FILL THE ENGINE'S
CRANKCASE UNTIL THE OIL LEVEL IS LEVEL WITH THE UPPER MARKED
LINE ON THE DIPSTICK, THEN SCREW THE DIPSTICK BACK INTO
THE OIL FILL HOLE.
Before Starting the Generator Fuel tank capacity:15.0L(4gallons)
1. Check that the engine power switch is in its
"OFF" position,
2. Before the first use, remove the fuel
tank cap and fill the fuel tank with unteaded
gasoline, When fueling, be sure that the
fuel strainer is in place, Replace the fuel
tank cap. Thereafter, check the engine's
fuel gauge for the amount of unleaded
gasoline in the fuel tank. If necessary, FU_L LEVEL GAUGE
FUEL TANK CAP
refill the fuel tank with unleaded gasoline;
the generator must be turned off and
cooled down before refilling the fuel tank.
Use gasoline with a pump octane rating of 90 or higher.
We recommend unleaded gasofing because it produces
fewer engine and spark plug deposits and extends
exhaust system Bile.
Never use stale or contaminated gasoline or oil/gasoline __ __ ..
mixture. Avoid getting dirt or water in the fuel tank.
Owner's Manual
Operation (cont'd)
Starting
4. Operate the Recoil Starter:
Puff the starter grip lightly until you feel resistance,
then pull briskly. Return the starter grip gently.
Pulling the starter grip operates the recoil starter to
crank the engine
5. If the choke has been moved to the CLOSED
position to start the engine, gradually move it to the
OPEN position as the engine warms up.
Stopping Engine
1. Turn the engine switch to the OFF position,
2. Turn the fuel valve lever to the OFF position.
When the engine is not in use, leave the fuel valve in
the OFF position to prevent carburetor flooding and to
reduce the possibility of fuel leakage.
4000W Generator
Operation (cont'd)
Starting
1. Turn the engine switch to the ON position.
The engine switch enables and disables the ignition
system.
OFF: To stop the engine
ON: To run the engine
2. The fuel valve is located under the fuel tank . When
the valve lever is in the ON position, fuel is allowed
to flow from the fuel tank to the carburetor. Be sur
to return the fuel valve lever to the OFF position after
stopping the engine.
3. To start a cold engine, move the choke lever to the
CLOSED position. To restart a warm engine, leave the
choke lever in the OPEN position.
The choke lever opens and closes the choke valve in
the carburetor.
The CLOSED position enriches the fuel mixture from
starting a cold engine.
The OPEN position provides the correct fuel mixture
for operation after starting, and for restarting a warm
engine.
4000W Generator
Operation (cont'd)
Powering 120 Volt AC Tools And Equipment:
1. Prior to powering tools and equipment, make sure the generator's rated voltage, and amperage
capacity (120 V AC @ 27.5 AMPs) is adequate to supply all electrical loads that the unit will
power. If powering exceeds the generator's capacity, it may be necessary to group one or more
of the tools and/or equipment for connection to a separate generator.
CAUTION: ATTEMPTING TO POWER SENSITIVE ELECTRONIC EQUIPMENT
_ ITHOUT THE USE OF AN APPROVED LINE CONDITIONER MAY CAUSE
DAMAGE TO THE EQUIPMENT. ALL-POWER IS NOT RESPONSIBLE FOR
ANY DIRECT OR INDIRECT DAMAGE CAUSED BY FAILURE TO USE AN
APPROVED LINE CONDITIONER.
2. Once the generator is running, simply connect the power cords of 120 volt AC powered
tools and equipment into the 120 voEt AC dual outEets.
_ NOTE: THE GENERATOR FEATURES AN AC NON-FUSE THERMAL PROTECTOR
TO PROTECT THE AC CIRCUIT IN CASE OF AN OVERLOAD. SHOULD
AN OVERLOAD OCCUR, THE BREAKER WILL POP.
3. Disconnect all electrical powered tools and equipment from the generator's 120 volt AC
duel outlets.
4. After the engine and generator have completely cooled, store generator in a safe, clean, dry
location (if not already installed).
