Page 4 of 4 75.5739.04 ALLEGION 8310-836 20201103
Do not leave problems unresolved. If a satisfactory solution cannot be achieved after troubleshooting
a problem, please contact Allegion at 1-877-671-7011. If you must wait for the following workday to
call Allegion, leave the door inoperable until satisfactory repairs can be made. Never sacrifice the safe
operation of the automatic door or gate for an incomplete solution.
For more information, visit www.allegion.com.
TECHNICAL SPECIFICATIONS
CLEANING
To clean the plates, use only a damp, non-abrasive cloth. Regular cleaning with harsh solvents or
abrasive materials may cause deterioration of the paint coating. Ensure the user is aware of this
procedure.
Original Instructions | PLEASE KEEP FOR FURTHER USE - DESIGNED FOR COLOR PRINTING
Specifications are subject to change without prior notice.
All values measured in specific conditions.
SWITCH SUB-ASSEMBLY
Contact configuration: SPST N.O.
Switching voltage: 0.1 – 50 VDC
Switching capacity: 1 W
Switching current: 0.005 – 100 ma DC
Operating temperature: -32 – 212 °F (-35 – 100 °C)
PUSH PLATE ASSEMBLY
Base material: 6063 aluminum
Face plate material: 304 stainless steel
Switch actuator material: nylon 66
End cap material: UL94 ABS
Hardware material: stainless steel
Page 4 of 4 75.5739.04 ALLEGION 8310-836 20201103
The sensor manufacturer cannot be held responsible for incorrect installations or inappropriate adjustments of the sensor/device; therefore, the sensor
manufacturer does not guarantee any use of the sensor outside of its intended purpose.
The sensor manufacturer strongly recommends that installation and service technicians be AAADM-certifi ed for pedestrian doors, IDA-certifi ed for
doors/gates, and factory-trained for the type of door/gate system.
Installers and service personnel are responsible for executing a risk assessment following each installation/service performed, ensuring that the sensor
system installation is compliant with local, national, and international regulations, codes, and standards.
Once installation or service work is complete, a safety inspection of the door/gate shall be performed per the door/gate manufacturer recommendations
and/or per AAADM/ANSI/DASMA guidelines (where applicable) for best industry practices. Safety inspections must be performed during each service
call – examples of these safety inspections can be found on an AAADM safety information label (e.g. ANSI/DASMA 102, ANSI/DASMA 107).
Verify that all appropriate industry signage and warning labels are in place.
INSTALLATION/SERVICE COMPLIANCE EXPECTATIONS
