WZ14:4:2+
USER GUIDE 23
OPTIONS
The
Mix Wizard Series WZ14:4:2+ has a versatile architecture designed to satisfy your live
sound and recording requirements without modification. The following internal options are offered
to provide alternative settings for those applications which may demand them. These options
require resoldering of circuit board links and should only be carried out by competent technical
personnel. Further information is available from your service agent or the
WZ14:4:2+ SERVICE
MANUAL
.
CHANNEL PRE-FADE AUX SEND OPTIONS
The Pre-fade aux sends are set post-EQ and post-ON as standard. However, link options on each
mic/line channel 1-10 and stereo channels 11-12 and 13-14 circuit board assemblies allow pre-EQ
and/or pre-ON if required.
STEREO CHANNEL AUX SENDS
The stereo input channels allow stereo input signals to feed the auxiliaries as stereo pairs. By
removing a link the left input signal will feed AUX 1, 3, 5, and the right input signal will feed AUX 2,
4, 6.
CHANNEL DIRECT OUTPUT SOURCE
The direct outputs are sourced post-fader as standard. A link option is available on each channel
assembly to select a pre-fade source.
SYS-LINK
TM
OPTION
The SYS-LINK
TM
option is an internally fitted circuit board and wiring harness which can easily be
installed by your service agent. The
SYS-LINK
TM
option allows up to five ALLEN & HEATH
consoles to be electronically connected together via a 25 pin D type multiway interconnecting cable
to provide more inputs to the mix.
RIAA OPTION
An RIAA PCB assembly plus earth post can be fitted to input A of each of the two stereo input
channels to allow connection for a turntable. Contact your dealer or service agent.
