ALLEN & HEATH Qu-16 User Manual

Qu Mixer User Guide 4 AP9372 iss.4
1. Packed contents
Options and Accessories available
Qu Mixer
Safety Sheets
AP3345 – English
AP7287 – French
AP8513 – Chinese
• Read this before starting
Mains lead • Check this
is correct for your territory
User Guide
A
P9372
REGISTER YOUR PRODUCT online at: http://www.allen-heath.com
Qu-Pad app for iPad
Available from the Apple Store
LEDlamp
Right angled 4-pin XLR
LED lamp with built-in
dimmer
Part: LEDlampX
Remote Audio Racks
Provides remote audio over dSNAKE Cat5 cable digital snake.
AR2412 24 Mic/Line in, 12 Line out AR84 8 Mic/Line in, 4 Line out
Part: GLD-AR2412 Part: GLD-AR0804
19” Rack Ear Kit for Qu-16
To mount the Qu-16 in a standard 19” rack or
flightcase. These fit over the plastic trims.
Part: QU-16-RK19
AB168 16 Mic/Line in,
8 Line out Remote
AudioRack.
Part: AB1608
Soft cover
AP9262 Qu-16
AP9458 Qu-24
AP9639 Qu-32
Qu
Cat5 cables
For use with dSNAKE remote
audio
AH8822 2m (6.6’) short patch
AH9651 20m (66’) coil
AH9650 100m (330’) drum

ALLEN & HEATH Qu-16 Specifications

General

Sample rate	48 kHz
Channels quantity	16 channels
Digital sound processing	- bit
Output impedance	75 Ω
Built-in display	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	82 W
XLR out	12
RJ-45 ports quantity	1
Headphone connectivity	6.3 mm
Number of microphone inputs	16
DJ mixer	-
Product color	Black
USB connector type	USB Type-A, USB Type-B

Weight and Dimensions

Depth	500 mm
Width	440 mm
Height	186 mm
Weight	10000 g
Package depth	680 mm
Package width	610 mm
Package height	350 mm
Package weight	13500 g
