ALLEN&HEATH Xone:42 Service Manual AP7207 Issue 1 Page - 6 - of 8
Nominal operating specifications
Nominal / Max output levels
Main Mix +4dBu +27dBu
Booth 0dBu +22dBu
X:FX Send 0dBu +20dBu
Record Out -10dBV +10dBV
Internal headroom
Channels +22dB
Frequency response +/-0.5dB 10Hz - 20kHz
Distortion < 0.03% THD+noise @1kHz
Crosstalk < -90dB inter-channel
Mic EIN 22Hz-22kHz -126dB 150 ohm source
Residual noise
Mix 1 -94dBu
Booth -101dBu
X:FX -92dBu
Rec -95dBu
Mix noise
Mix 1 -80dBu (-84dB S/N)
Booth -84dBu (-82dB S/N)
X:FX -88dBu (-84dB S/N)
Rec -90dBu
Channel meters Peak reading 9 LED -20dB to +10dB
Main meters Peak reading 9 LED -20dB to +10dB
Mic EQ 2-Band +/-12dB
Channel EQs 3-Band +6dB / total kill
Channel faders 60mm stereo VCA, < -90dB shutoff
Crossfader 45mm stereo VCA - replaceable
Consumption 30W max
