ALLEN & HEATH XONE:43C Quick Start Guide

Using the Tool Tips
Click on the icon to enable Tool Tips. This is located in between the
MIDI and setup button in the top right hand corner of the screen. Tool Tips
provide a handy way to learn the various features of Serato DJ.
Move the mouse over a section of the screen to bring up a context sensitive
tool tip. Holding the mouse over the button with Tool Tips turned on
will show you a list of all keyboard shortcuts.
For more information about how to use Serato DJ, please go to our website
www.serato.com or download the Serato DJ Manual.
For more information on your XONE:43C, please refer to the Allen & Heath
XONE:43C manual which can be downloaded from allen-heath.com.
For further help, please email support@serato.com or go to serato.com/
support
Recording
To record your mixes with Serato DJ and the XONE:43C you will need to
designate a mixer channel to use for recording. You will not be able to use
this channel in Serato DJ while it is used for recording.
Connect an RCA cable from the Record output on the back of the mixer to
the input of the channel you have nominated. Open the REC panel inside
Serato DJ and select this channel as your recording input. This will record the
software mix.
See the XONE:43C User Guide for more information.
MIDI
The MIDI control feature in Serato DJ provides the ability to map Serato DJ
software functions to MIDI controller functions such as keyboards, triggers,
sliders, and knobs.
Integrating MIDI controllers into your Serato DJ setup can improve live
performance usability, such as hitting pads on a MIDI controller to trigger
Loops or Cue Points. Buttons marked as ‘MIDI mappable’ can be MIDI
mapped the the Serato DJ function of your choice.
For further information on how to MIDI map Serato DJ software functions,
please refer to the Serato DJ manual.
NOTE: You can not change the functionality of other buttons by using the
MIDI control features. You will need to connect a secondary MIDI controller
to take advantage of MIDI control.

ALLEN & HEATH XONE:43C Specifications

General

Sample rate	96 kHz
Channels quantity	16 channels
Digital sound processing	24 bit
Line Signal-to-Noise Ratio (SNR)	20 dB
Total Harmonic Distortion (THD)	0.05 %
Microphone in	Yes
Headphone connectivity	3.5 mm
Product color	Black
Video capability	No
Power consumption (typical)	30 W
Equalizer bands quantity	3

Weight and Dimensions

Depth	370 mm
Width	320 mm
Height	110 mm
Weight	5200 g
