X:LINK
Connect XONE:K Series Controllers to the XONE:96 for remote software MIDI control and saving use of computer USB ports.
RJ-45, Ethernet.
MIDI OUT
MIDI signal output for syncing to external MIDI hardware.
5-pin DIN.
USB 1 and USB 2 Soundcards
Dual 24 Channel (6 Stereo IN/6 Stereo OUT), 32Bit/96kHz, internal Hi-Speed USB soundcards. macOS class compliant. Direct full-duplex MIDI between USB 1 & USB 2.
USB-B.
RECORD Outputs
Pre-Master (MST) level, LR MIX output for connection to external hardware recording devices.
Unbalanced RCA.
LINE Inputs, CH 1 - 4
Connect stereo LINE level media players to the LINE inputs. Do not connect turntables requiring RIAA equalisation.
Unbalanced RCA.
PHONO Inputs, CH 1 - 4
Connect turntables with magnetic cartridges requiring RIAA equalisation to PHONO inputs. For non-RIAA turntables plug into the LINE input instead.
Unbalanced RCA.
USB LINE / PHONO Select Switches, CH 1 - 4
Set CH1 - 4 USB sources to LN or PH for LINE or RIAA signal level input to internal soundcards. For DVS (CD/Vinyl timecode) control, or recording CH1 - 4 inputs via USB.
Chassis Earth Terminals
2 x Screw terminals are provided for connecting the earth straps from turntables to prevent ground hum.
Audio Sync Out
Enables future Allen&Heath accessories to be easily connected to the XONE:96.
Alternative Secondary Record Output, pre-MASTER level, LR MIX output for connection to external devices.
Stereo 3.5mm mini-jack.
MIC A / MIC B Inputs
Use superior quality low impedance dynamic mics. Do NOT use high impedance or unbalanced mics, or condenser mics requiring phantom power.
Balanced XLR, wired; Pin1=Ground, Pin2=Hot [+], Pin3=Cold [-].
AC Mains Input
Connect (supplied) IEC cable with moulded plug compatible to local AC mains supply. Turn AC supply to the mixer ON / OFF.
MST 1, MASTER Outputs
Main stereo LR MIX outputs that feed the club PA system, or active speakers.
Balanced XLR (female), wired; Pin1=Ground, Pin2=Hot [+], Pin3=Cold [-].
MASTER INSERT SND / RTN
Provides INSERT points for LR MIX output to connect hardware dynamics processors such as a limiter, compressor, or graphic equaliser.
Or connect effects hardware in-line with the LR MIX for external MASTER INSERT FX processing. INSERTS route via MAIN LR bus affecting MST1, MST2 and BOOTH outputs
INSERT SND: Balanced (TRS) ¼“Jack, wired; Tip=Hot [+], Ring=Cold [-], Sleeve=Ground. INSERT RTN: Unbalanced (MONO) ¼”Jack, wired; Tip=Hot [+], Sleeve=Ground.
MST 2 Outputs
Alternative stereo MIX output to feed additional zone, consumer amplifier, or active speakers.
Balanced (TRS) ¼“Jack, wired; Tip=Hot [+], Ring=Cold [-], Sleeve=Ground.
BOOTH Outputs
Balanced LINE level stereo output feed to DJ’s local monitor system, or active speakers.
Balanced (TRS) ¼“Jack, wired; Tip=Hot [+], Ring=Cold [-], Sleeve=Ground.
RTN C / RTN D, Auxiliary Return Inputs
Connect auxiliary LINE level music sources, or external effects outputs to route direct to LR MIX. Connect MONO devices via the L/M socket.
Use RTN C / RTN D top panel controls to adjust signal levels sent to the mix.
Unbalanced (MONO) ¼“Jack, wired; Tip=Hot [+], Sleeve=Ground.
RTN A / RTN B, LINE Inputs
Connect auxiliary LINE level music sources, or external effects device outputs to RTN A and RTN B LINE inputs to route to CH A and CH B. Connect MONO devices via L/M.
Balanced (TRS) ¼“Jack, wired; Tip=Hot [+], Ring=Cold [-], Sleeve=Ground.
SND 1 / SND 2, LINE Outputs
Connect your external FX inputs to SND 1 or SND 2 outputs and use SEND 1 / SEND 2 controls to send Channel audio to the FX unit. Connect MONO devices via L/M.
Switchable SND 1 input and RTN A output impedance for external FX between LN, or Hi-Z suitable for guitar FX pedals or legacy hardware.
Balanced (TRS) ¼“Jack, wired; Tip=Hot [+], Ring=Cold [-], Sleeve=Ground.
K-Slot
Security slot to connect locking, Kensington® type, anti-theft cable.
Rear Panel Overview cont.
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
18
19
9
